Carb Build Tutorial
« on: November 23, 2011, 08:49:14 PM »

I snapped some pics of the last build I did, and added some captions for anyone who they will help. This was after it had all been in the Berryman's Chemdip overnight, blown off with air and then liberally wd40'd. I was always going to do this and then Louis made his, so no need to retrace his footsteps or attempt to rival his efforts. These are stills. The flash changes some things. It makes the welch plugs look very wacky, and they aren't really caved in as much. Otherwise I hope it helps someone. Feel free to download them. I also have them all on 1 page as a high rez pdf. You can email me for that. doublet@twcny.rr.com.




Report to moderator Logged

'65 Olympique
SurgeSurge
Boardnation God
*****

Posts: 357



I love Boardnation!

View Profile
Re:Carb Build Tutorial
« Reply #1 on: November 24, 2011, 06:38:41 AM »

Thanks Hermit thats awesome!!!!  How to I get them to print?
Report to moderator Logged
hermit
Global Moderator
*****

Posts: 3605



I love Boardnation!

View Profile E-Mail
Re:Carb Build Tutorial
« Reply #2 on: November 24, 2011, 10:45:07 AM »

Either right(?) click them to download or I can email you the files. doublet@twcny.rr.com
Report to moderator Logged

'65 Olympique
moxymech1
Guest

E-Mail
Re:Carb Build Tutorial
« Reply #3 on: November 24, 2011, 11:26:27 AM »

email sent

moxy
Report to moderator Logged
lshobie
Guest

E-Mail
Re:Carb Build Tutorial
« Reply #4 on: November 24, 2011, 01:54:08 PM »

Very nice, it's good to have a a hard copy of this type of thing.

I've made this topic a sticky and will add my videos as well, carb rebuilding is a popular topic and all of this info is very helpful and should be at the top.

Rebuilding a Tillotson carb - video tutorial:

http://www.youtube.com/watch?v=JZP2Yr9o7-Y

How a mikuni carb works:

http://www.youtube.com/watch?v=a5p6YScsTNQ

#1 Mikuni fuel pump rebuild
http://www.youtube.com/watch?v=Z0LRwwmkkUM

#2 Tear down and cleaning

http://www.youtube.com/watch?v=AOJlHIUUBk0

#3 assembly

http://www.youtube.com/watch?v=wfVQUBO7LjQ
« Last Edit: November 24, 2011, 02:01:21 PM by lshobie » Report to moderator Logged
hermit
Global Moderator
*****

Posts: 3605



I love Boardnation!

View Profile E-Mail
Re:Carb Build Tutorial
« Reply #5 on: November 24, 2011, 10:24:59 PM »

Cool! I know it's pretty basic and most is common knowledge but if it helps even a couple guys or answers a question or 2 it's worth it.
